Elevator Control System
Your Professional Elevator Control System Supplier
STEP Electric Corporation is an industrial inverter supplier with research and development centers and manufacturing bases in both China and Germany.
Why choose us
Our Certifications
The product meets the EN81-20 safety standard, ensuring compliance with European
elevator regulations. It is also CE certified, confirming adherence to European
health, safety, and environmental protection standards. The product follows ISO
standards, guaranteeing quality and consistency. It has passed TÜV
certification,
indicating it meets rigorous safety and quality requirements. Additionally, it
holds
the CCC certification, proving compliance with Chinese safety standards.
Furthermore, it is recognized with the Q+ Plus certification, showcasing its
high-quality performance.
Sales Market
Our products and services are widely welcomed by customers in over fifty
countries
and regions, including Germany, Malaysia, Vietnam, Indonesia, Singapore,
Australia,
India, Turkey, Kenya, South Africa, and many others.
Multi-language Support
Yixin International is a comprehensive international trading company with
multi-language business support, including English, Spanish, Russian, and
others.
While designing the elevator integrated drive and controller, a variety of factors, including elevators' safety and reliability, inherent characteristics of elevator operation, and potential energy load characteristic of elevators, are taken into consideration.
Designed based on variable frequency speed regulation technology and elevator control technology, the elevator integrated drive and controller is an ideal combination of an elevator drive and an elevator controller.
Its dual 32-bit embedded microprocessor unit allows it to complete both elevator operation and motor drive functions.
It also features compact structure, small size, few wire connection and high reliability.
Specification Data
|
Model AS380 |
Rated capacity (kVA) |
Rated output current (A) |
Rated power of motor (kW) |
Model AS380 |
Rated capacity (kVA) |
Rated output current (A) |
Rated power of motor (kW) |
|
200V-level |
400V-level |
||||||
|
2S01P1 |
2.3 |
6.0 |
1.1 |
4T01P1 |
2.7 |
3.5 |
1.1 |
|
2S02P2 |
4.6 |
12 |
2.2 |
4T02P2 |
4.7 |
6.2 |
2.2 |
|
2S03P7 |
6.9 |
18 |
3.7 |
4T03P7 |
6.9 |
9 |
3.7 |
|
2S05P5 |
9.5 |
25 |
5.5 |
4T05P5 |
8.5 |
13 |
5.5 |
|
2S07P5 |
12.6 |
33 |
7.5 |
4T07P5 |
14 |
18 |
7.5 |
|
2S00P11 |
17.9 |
47 |
11 |
4T0011 |
18 |
27 |
11 |
|
2S00P15 |
23 |
60 |
15 |
4T0015 |
24 |
34 |
15 |
|
2S18P5 |
29 |
75 |
18.5 |
4T18P5 |
29 |
41 |
18.5 |
|
2S00P22 |
32 |
80 |
22 |
4T0022 |
34 |
48 |
22 |
|
4T0030 |
50 |
65 |
30 |
||||
|
4T0037 |
61 |
80 |
37 |
||||
|
4T0045 |
74 |
97 |
45 |
||||
|
4T0055 |
98 |
128 |
55 |
||||
|
4T0075 |
130 |
165 |
75 |
||||
Technical Indicators
|
Item |
Indicators |
|
|
Maximum output voltage |
Input voltage |
|
|
Input power supply |
Number of phases, voltage, and frequency |
200V-level: ≤3.7kW single phase or three phase 220V 50/60Hz; |
|
Voltage range |
-15%-+10% |
|
|
Frequency range |
-5%~+5% |
|
|
Instantaneous voltage drop |
200V-level: Input voltage < AC180V, low-voltage protection
after |
|
|
Basic features |
Floor number |
2-64 |
|
Elevator rated speed |
≤4.00m/s |
|
|
Group control units |
≤8 units |
|
|
Communication mode |
CAN-Bus |
|
|
Control features |
Control mode |
Close loop vector control |
|
Overload capacity |
Zero speed, 150%;< 3Hz,160%; > 3Hz, 200% |
|
|
Braking torque |
150% (External brake resistor), built-in brake unit |
|
|
Protection grade |
IP20 |
|
|
Installation mode |
Installed in the cabinet |
|
Installation Information
|
Model of AS380 |
A |
B |
H |
W |
D |
Installation aperture < Φ (mm) |
Installation |
Tightening torque (Nm) |
Mass (kg) |
||
|
Bolt |
Nut |
Gasket |
|||||||||
|
2S01P1 2S02P2 2S03P7 |
100 |
288.5 |
300 |
160 |
166 |
5.0 |
4M4 |
4M4 |
4φ4 |
2 |
4.5 |
|
2T05P5 2T07P5 2T0011 |
165.5 |
357 |
379 |
222 |
185 |
7.0 |
4M6 |
4M6 |
4φ6 |
3 |
8.2 |
|
2T0015 2T18P5 2T0022 |
165 |
440 |
465 |
254 |
261 |
7.0 |
4M6 |
4M6 |
4φ6 |
3 |
10.3 |
|
4T02P2 |
100 |
288.5 |
300 |
160 |
166 |
5.0 |
4M4 |
4M4 |
4φ4 |
2 |
4.5 |
|
4T07P5 |
165.5 |
357 |
357 |
379 |
222 |
7.0 |
4M6 |
4M6 |
4φ6 |
3 |
8.2 |
|
4T0015 4T0022 |
165.5 |
392 |
414 |
232 |
192 |
7.0 |
4M6 |
4M6 |
4φ6 |
3 |
10.3 |
|
4T0030 4T0037 |
200 |
510 |
530 |
330 |
290 |
9.0 |
4M8 |
4M8 |
4φ8 |
6 |
30 |
|
4T0045 |
200 |
587 |
610 |
330 |
310 |
10.0 |
4M8 |
4M8 |
4φ8 |
9 |
42 |
|
4T0055 |
200 |
587 |
610 |
330 |
310 |
10.0 |
4M10 |
4M10 |
4φ10 |
14 |
42 |
|
4T0075 |
320 |
718 |
750 |
430 |
351 |
13.0 |
4M13 |
4M13 |
4φ13 |
29 |
79.5 |
The elevator integrated drive and controller is designed with closed loop vector controller for higher performance.
Zero-speed torque compensation system without load weighing device helps save cost.
New PWM dead-zone compensation technology is conducive to energy conservation.
Dynamic PWM carrier modulation technology ensures reduced motor noise.
The elevator integrated drive and controller is suitable for both synchronous and asynchronous motor.
Dual 32-bit embedded microprocessor.
Incremental encoder is employed to control synchronous motor.
This product is applicable for residential lift, goods lift, car lift, ramp elevator, etc.
Motor Wiring
It is forbidden to short circuit or ground the Elevator Drive Controller output terminal, otherwise the internal components of the integrated controller will be damaged.
Do not short circuit the output cable and the integrated controller enclosure, otherwise electric shock may happen.
It is forbidden to connect the output terminal of the integrated controller to the capacitor or LC/RC noise filter with phase lead, otherwise, the internal components of the integrated controller may be damaged.
When contactor is installed between the integrated controller and motor, it is forbidden to switch on/off the contactor when the integrated controller is running; otherwise, large current will flow into the integrated controller, triggering the integrated controller protection action.
The lift serial inverter is compatible with smart phone tuning with comprehensive information. Support parameters and error data remote transfer, online guidance, balance coefficient detection and other functions.
The lift serial inverter tuning process is easy and efficient by simple auto-tuning (self-learning) operations to get motor parameters and initial angle for both rotating and static methods.
When working with Bluelight synchronous traction machine, the lift serial inverter could use predefined machine model information to improve commissioning efficiency and maximize machine performance.
Highly Reliability
Advanced two 32-bit CPU and a FPGA cooperation for complete elevator controller system to ensure high elevator safety. Redundancy lift serial inverter design and full software-hardware protection to guarantee elevator safety and reliability.
Professional EMC tested integrated controller, enhanced anti-electromagnetic interference ability and suitable for complicated job site. Monitoring the cutting current from lift serial inverter to traction machine every time when elevator stops.
